Conical Rounder HMQ-30

Model: HMQ-30

Voltage/Power: 380V/1.1kw

Output: 1P(2500pcs/hour)

Dough weight range: 1P(50-250g)(100-1000g)(200-1000g)

Weight: 210kg

Machine size O.D: 950*950*1520mm

E-mail：export@homat.com.cn

Detail

Machine features:
1. The machine body is made of high-quality wear-resistant steel, and the outer surface and guide rails are coated with wear-resistant Teflon, which will not stick to the dough. The cone spiral guide rail is made of aluminum alloy and precisely assembled to ensure the perfect contact angle between the guide rail and the cone, thereby ensuring the roundness of the dough.
2. The equipment can be used independently or combined with a block divider to form a production line.
3. The guide rail is movable and adjustable, suitable for rolling large and small dough.

Divider&Rounder Specification

Model	HMD-1P	HMQ-30
Voltage(V)	380	380
Power(Kw)	1.5	1.1
Production capacity	1P(2500pcs/hour)	1P(2500pcs/hour)
Dough weight range(g)	1P(50~250)(100~1000)(200~1000)	1P(50~250)(100~1000)(200~1000)
Weight(Kg)	410	210
Length(mm)	650	950
Depth(mm)	1780	950
Height(mm)	1600	1520

1.Inspect by Quality Inspect Dept. before packing
2.After approved,clean thoroughly
3.Put desiccant inside to prevent damage by humid air,because the humidity is 15 times higher than normal while shipping
4.Put 6cm thick foam board around
5.Fasten with stretch film around,bubble film,and stretch film again
6.Wooden packing, and reinforce with steel belt
7.According to different products, reinforce before loading to the container to prevent damage in transport
